EUROMET SN-200 tool grinding machine

Tool grinding machines

EUROMET SN-200 tool grinding machine

71 552,25 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Michał Bartoszuk
E-mail: michal.bartoszuk@eurometal.com.pl
Telefon: 603505252

The EUROMET SN-200 tool grinder is a universal device, used for precise and final machining of all types of cylindrical, flat and other non-standard surfaces. It is characterized by the basic features of shaft grinders, surface grinders and tool sharpeners.

Quantity

The main purpose of the SN-200 multifunction grinder is to carry out broadly understood, small grinding works and sharpening tools.

On the device, it is possible to grind both external and internal surfaces, e.g. pipes, thanks to the use of a special head, which is a standard equipment of the machine.

Standard equipment:

cooling system
grinding wheel - 6 pcs.
internal grinding head
spindle for external grinding
3-jaw chuck
canine
steady rest
left tailstock
dresser (without diamond)
wheel puller - 3 pcs.
V-belt - 2 pcs.
static balancing machine for grinding wheels
grinding wheel flange - 3 pcs.
centering sleeves - 2 pcs
grinding wheel guard - 2 pcs.
manual in English

Optional equipment (additionally payable):

dust extraction
magnetic worktable
attachment for grinding drills
universal dresser for a grinding wheel

Technical data	Unit	Value
Workpiece diameter	[mm]	200
Grinding length	[mm]	500
External grinding diameter range	[mm]	5 - 50
Internal grinding diameter range	[mm]	10 - 50
Grinding length for external grinding	[mm]	400
Grinding length for internal grinding	[mm]	75
Maximum dimensions of surface grinding	[mm]	100 x 50
Maximum workpiece weight	[kg]	10
The height of the axis of the workpiece head	[mm]	100
Center distance between the workpiece head and the tailstock	[mm]	430
Spacing of tusks between the right and left tailstock	[mm]	500
Spindle taper	[-]	Morse 2
Spindle speed	[rpm/min]	110 - 300
Workpiece head rotation angle	[°]	+/- 90
Vertical movement of the grinding wheel head	[mm]	200
Cross travel of the grinding wheel head	[mm]	200
Vertical feed per handwheel revolution	[mm]	1
Vertical feed per one plot	[mm]	0,01
Cross feed per handwheel revolution	[mm]	0,25
Cross feed per plot	[mm]	0,005 - 0,02
The angle of rotation of the grinding wheel head in the horizontal plane	[°]	+/- 90
The rotational speed of the grinding wheel	[rpm/min]	2950
The dimensions of the grinding wheel	[mm]	200 x 20 x 7
Maximum travel of the worktable	[mm]	480
Cross feed (hydraulic)	[mm]	0,1 - 6
Cross feed (servo motor)	[m/min]	≤7
The feed of the working table per one turn of the knob	[mm]	17
The feed of the working table per one turn of the knob	[mm]	126
Maximum angle of rotation of the upper table	[°]	+45/-30
Tailstock cone	[-]	Morse 2
Tailstock sleeve travel	[mm]	14
Working pressure of the hydraulic system	[MPa]	0,8 - 1,2
Auxiliary pressure	[MPa]	0,5 - 0,6
Lubrication pressure	[MPa]	0,08 - 0,15
Coolant pump capacity	[l/min]	22
Grinding wheel head motor power	[kW]	1,1
Workpiece head motor power	[kW]	0,18
Hydraulic pump motor power	[kW]	0,75
Coolant pump motor power	[kW]	0,125
Chip separator motor power	[kW]	0,75
Total power	[kW]	2,525
The level of noise emitted does not exceed	[dB]	79
Dimensions	[mm]	1520 x 1131 x 1173
Net weight	[kg]	1350
