Universal /manual lathes

UNIVERSAL LATHE EUROMET VD320X880

15 900,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

The universal lathe VD320x880 is a machine of small dimensions, with electronically controlled rotation speed, easy to use with intuitive adjustments. It has a wide range of possible works, it can perform external, internal, face and final turning. It is equipped with the possibility of cutting both metric and inch threads. It can be used both in home workshops and for small works in company workshops. An excellent lathe for training in a profession in schools, institutes and other positions where precision and speed of production of details and repair of other devices is essential.

Quantity
Add to cart

The universal lathe VD320x880 is a machine of small dimensions, with electronically controlled rotation speed, easy to use with intuitive adjustments. It has a wide range of possible works, it can perform external, internal, face and final turning. It is equipped with the possibility of cutting both metric and inch threads. It can be used both in home workshops and for small works in company workshops. An excellent lathe for training in a profession in schools, institutes and other positions where precision and speed of production of details and repair of other devices is essential.

Standard equipment:
  • 4-jaw lathe chuck
  • Led lighting
  • Stepless speed regulation adjustable in 2 ranges
  • Metal base with built-in drawers and a tool cabinet
  • Spindle cover
  • Post cover
  • Lead screw cover
  • 2 axis digital readout
  • Machine manual in English
  • CE declaration of conformity

Technical data Unit Value
Turning diameter over bed [mm] 320
Turning diameter over cross slide [mm] 200
Turning length [mm] 880
Spindle flight [mm] 38
Spindle speed range [rpm/min] 75 - 2250
Spindle bore cone [-] MT5
Maximum tool dimensions [mm] 0,20-3,5(18 wartości)
Longitudinal feed range [mm/rpm] 0,017 - 0,25
Przesuw poprzeczny [mm] 420
Cross travel range [mm/rpm] 0,07 - 0,52
Metric thread [mm] 16x16
Inch thread [-] 8-56 T.P.I. (21 wartości)
Tailstock sleeve diameter [mm] 32
Extend the tailstock quill [mm] 80
Tailstock sleeve tip [-] MT3
Engine power [kW] 1,5
Tool post travel [mm] 230
Dimensions [mm] 1600x750x700
Weight [kg] 300
